ATIM | Dry Contacts or Metering monitoring/controlling 88/160

This LoRaWAN sensor monitors up to 16 dry contacts or metering inputs and enables remote controlling of up to 8 digital outputs. It can be used to control and localize equipment, remote control and restart of equipment (pumps, motors, valves, etc).

(VAT excluded)
In stock
Usually delivered in 10 working days
Commercially available
This product is already in mass production. Production batches are in route or stock is available. All certifications for the regional areas where the products are sold are obtained from competent institutions.

Key features highlights :

  • LoRaWAN class C
  • GPS option
  • External temperature probe option
  • Plug and Play
  • Remotly control

Description :

The ACW/LW8-DIND88 is an Industrial Internet of Things (IIoT) device in DIN format ready to be installed in an electrical cabinet in order to monitor it.

Each of the inputs (8 or 16 depending on the selected version) can be configured as dry contact input or as counting.

A version with 8 inputs and 8 outputs ToR for controlling equipment or restarting remotely from the network is also commercially available.

The ACW/LW8-DIND88 also tracks the GPS position and/or an external temperature probe (optional).

This product can be used in a different ways:

  • Control monitoring and geolocation of equipment (electrical boxes, generators, air compressors, etc.)
  • Intrusion detection (replacement of old RTC alarms)
  • Control and restart remote equipment (pumps, motors, valves, etc ...)
Specifications :
Seller ATIM
Manufacturer Name ATIM
SKU 66-6794
Manufacturer Part Number ACW/LW8-DIND88/160
Product Attributes Metering
Product Capabilities Electric Smart metering
LoRa Class Class C
Other Protocol LoRaWAN
Solution Represented Smart Industries, Location & Asset Tracking, Smart Metering
Power Supply Electrical power
Battery Type 12V input
Antenna External on connector
Interfaces Numerique, USB
Operating Temperature (Min to Max) -20°C | +55°C
Depth (cm) 6,7
Width (cm) 9,5
Height (cm) 5,3
Lead-time if backordered (in working days) 30
Lead-time if in stock (in working days) 10
