Kerlink Wirnet iBTS Compact Outdoor Gateway (1 LOC/ 1 WAN)

The Wirnet iBTS IoT gateway is a robust, performant and highly scalable outdoor LoRaWAN gateway for smart IoT networks.

Its carrier-grade conception offers powerful embedded processing capabilities, secure design, advanced remote monitoring options, and enhanced radio network configuration, easy to operate even for non-telecom users.

Select the prestaging platform depending on your use:

  • For proof of concept and non-commercial use, we recommend our cloud-based ThingPark Community platform which is free to use.  If you choose this option, the ThingPark team will pre-configure and provision your gateway(s) on ThingPark Community platform. If you do not already have an account on this platform, the ThingPark team will create one for you, using your registered email address.

  • For commercial operation, we recommend using our ThingPark Enterprise SaaS production platform (TPE SaaS) or ThingPark Enterprise On-Premise platform (OCP) . TPE SaaS is georedundant, fully managed 24*7 and provides SLAs. “ThingPark Enterprise (TPE) OCP is a full on-premise platform, available both in standalone or High-Availability deployment modes To use TPE SaaS or TPE OCP, you need an active subscription. Use these options for commercial deployments and select the right region.

(VAT excluded)
In stock
Usually delivered in 5 working days
Commercially available
This product is already in mass production. Production batches are in route or stock is available. All certifications for the regional areas where the products are sold are obtained from competent institutions.

Key features highlights :

  • Outdoor LoRa® Gateway,
  • Supported unlicensed bands: 863-874.4MHz (EMEA, India), 902-928MHz (North America), 915-928MHz (APAC, Latin America),
  • Supported LoRaWAN® regional parameters: EU863-870, US902-928, AS923 (LTE Module MC7304 compatible only for Hong Kong, Indonesia, Malaysia, and Vietnam)
  • Modular configurations:
    • from 16 channels (1 x LoRa RF modem) to 80 channels (4 x
      LoRa RF modem),
    • Single omnidirectional antenna, spatial diversity, dual-polarization, tri-sectorization,
    • Possibility to support multiple unlicensed bands in a single gateway,
  • Backhaul Connectivity: Cellular 2G/3G/4G evolutive to 5G (mini-PCIe module), Ethernet 10/100 Mbps (RJ45),
  • Geolocation ready: Using the fine timestamps on ALL the channels for improved geolocation services thanks to FPGA. Fully compliant with Semtech reference design v2. No proprietary locked solution; Synchronization with GPS, combines RSSI and TDOA measurements.

Description :

The “Wirnet™ iBTS” is the ideal gateway to support your smart city, smart building, or every smart project as it combines excellent Outdoor coverage (more than 15km in direct line-of-sight and 2km in an urban environment) and operational excellence.

Already widely deployed worldwide to power tier-one operators’ networks, it is available in most global unlicensed frequency bands (like ISM).

The Wirnet iBTS Compact version will be the perfect match for operators and enterprises looking for a turnkey solution, offering the first light and compact form factor. Il will simplify installation with its built-in mono or dual-WAN backhaul and integrated antennas for GPS receiver and 2G/3G/4G cellular modem.

 This LoRaWAN gateway is fully compatible with LoRa® native sensors geolocation and can be remotely monitored and managed with Kerlink network operations solutions, the Wanesy Management Center.

Compact configuration:

  • 1 x UC module,
  • 1 x WAN module,
  • 1 x LoRa® RF modem module (16 channels),
  • Size: 357 x 189 x 150 mm (including mounting kit),
  • Ingress protection (IP67),
  • Weight: about 3 kg (including mounting kit).

Key Differentiators:

  • High performance, reliability & future-proof
  • Semtech Reference Design v2,
  • Built-in high-rejection filters,
  • LoRa-ETM Ready: Evolutive design using modem SDR (Software Design Radio) architecture. Secure HW and SW architecture
  • SecureBoot (Signed firmware),
  • SecureStorage (keys and certificates in the secured area) using ProvenCore™ solution,
  • Secured links and backhaul protection (OpenVPN/IPsec),
  • Reboot (watchdog) and recover to the previous Management config (or factory config if the boot issue is not fixed).

Important: PoE + LoRa Antenna are not supplied. You can buy the antennas here and the PoE here.

Optional backhaul as a service with Actility global SIM

Streamline delivery, installation, and operational processes with Ready-to-Use Pre-connected LoRaWAN gateways including backhaul connectivity powered by Actility global IoT SIM.

Pre-configured LoRaWAN gateways are ready for the plug-in, minimal-cost installation. However, due to IT security policies, it is increasingly difficult to use the existing LAN for backhaul IP connectivity. The perfect solution is to equip LoRaWAN gateways with our global IoT SIM: just ship to the customer site, and the private network will be immediately operational as soon as the gateway is plugged into the main power.

For the list of supported countries per region, visit here. Don't hesitate to get in touch with us if your country is not on the supported list.

Note: The service is primarily restricted to LTE-only coverage. If you are in a region that has only 3G coverage, please contact us.

Specifications :
Seller Actility
Manufacturer Name Kerlink
Seller SKU GWKLK2500
Product Attributes Gateway
Solution Represented Smart Cities, Smart Industries
Gateway Type Outdoor Gateway
Width (cm) 189
Height (cm) 357
Depth (cm) 150
Lead-time if in stock (in working days) 5
Lead-time if backordered (in working days) 15
Power Supply Electrical power
Power Supply Power Over Ethernet 30W
Battery type Other
Sensor sensibility -141 dBm (SF12)
LoRa Class Class A, Class B, Class C
Ingress protection IP66
Operating Temperature (min to max) Range -40°C +60°C, (for gateway only, without power supply)
Environmental conditions Humidity: 5% to 95%
