NETVOX WIRELESS CO DETECTOR RA02C AS923

RA02C is a device for the detection of harmful gases in the home environment. It is suitable for the detection of CO (carbon monoxide). When the concentration exceeds the preset value, it will trigger the alarm and fully comply with the LoRaWAN protocol standard.

$84.28
(VAT excluded)
In stock
Production ready
Product design is finalized. Bill of Materials is finalized. An initial important batch of products to make the SKU commercially available is required, meaning no inventories are currently available and lead time is in months. All final certifications are not obtained yet but pre-testing has been operated and seller is 100% sure to obtain them. Datasheet and user guide should already be available.

Key features highlights :

Electric

Power Input 2*AAA alkaline battery
Standby Current 18uA/3VDC
Average Operating Current 70uA/3VDC
Current While alarming 20mA/3VDC
Alarm Sound Intensity 85dBm at 3m
CO Detection Concentration Range 0 ~ 1000ppm

Frequency

TX Power 19dBm±1dBm
Rx Sensitivity -136dBm (LoRa,Spreading Factor=12, Bit Rate=293bps ) -121dBm (FSK,Frequency deviation=5kHz, Bit Rate=1.2kbps)
Antenna Type Build-in antenna
Communication Range 10 km (line-of-sight, the actual transmission distance depends on the environment)
Data Transfer Rate 0.3kbps~50kbps
Spread Technique LoRa/FSK
Available Frequency EU863-870,US902-928,AU915-928,KR920-923,AS923,CN470-510 Configured before shipment


Physical

Dimension D106mm , H36mm
Operating Temperature Range -20℃ ~ 55℃
Operating Humidity Range < 90%RH (no condensation)
Storage Temperature range -40℃ ~ 85℃




Description :

RA02C is a wireless control alarm device for smart home and high reliability. It adopts wireless communication method conforming to the LoRaWAN protocol standard. RA02C is a device for the detection of harmful gases in the home environment. It is suitable for the detection of CO (carbon monoxide). When the concentration exceeds the preset value, it will trigger the alarm and fully comply with the LoRaWAN protocol standard.

Specifications :
Seller netvox
Manufacturer name Netvoc
SKU 114-6540
Manufacturer Part number RA02C
Product Attributes Metering, Smoke Detection
Product Capabilities Carbon Monoxyde (CO) sensor, Carbon dioxide (CO₂) Sensor, Gas sensing, Smoke detector
RF Region AS923 - Asia 915-928MHz
LoRa Class Class A
Other protocol LoRaWAN
Use Case Air quality monitoring, Fire prevention, Leak detection
Solution Represented Smart Cities, Energy and Utilities, Facilities Management, Smart Building, Daily Life
Power supply Replaceable battery
Battery specification (Wh) 2x AAA alkaline battery
Battery type Alkaline
Antenna Integrated
RF transceiver SX1276
Internal sensors utility Smoke and Gas, Other
Operating Temperature (min to max) -20℃ ~ 55℃
Depth (cm) 3.6
Height (cm) 10.6
Technical documents
