Smartico Gas Shutoff Valve LoRaWAN V-LR

The Gas Shutoff Valve LoRaWAN “Smartico V-LR” was designed for remotely shut off the gas supply in the low pressure gas network.

$120.65
(VAT excluded)
Out of stock
Available on: 24-05-2023
Commercially available
This product is already in mass production. Production batches are in route or stock is available. All certifications for the regional areas where the products are sold are obtained from competent institutions.

Key features highlights :

Closing the valve if unauthorized external intervention was happened and transmitting an alarm message to the dispatcher's software.
Operation mode displayed by leds.
Monitoring and transmission of the following parameters:
• battery discharge;
• operability of internal sensors;
• strikes and changes in position;
• opening the case;
• current valve state.
Built-in non-volatile memory, events archiving, built-in real-time clock.
Data transmission in the unlicensed frequency range.
Remote blocking of gas supply from the dispatcher console.
Encryption of data transmission.
Response time - less than 1 s.
Small dimensions, ease of installation.
Battery life up to 15 years.

Description :

The Gas Shutoff Valve LoRaWAN “Smartico V-LR” was designed for remotely shut off the gas supply in the low pressure gas network. The shut-off valve was made with autonomous power supply. It has a special valve activation mechanism that allows safe recovery of gas supply. Places of installation of protective seals are provided to prevent unauthorized access to the power source and exclude the possibility of dismantling the valve from the connecting gas pipeline.



Specifications

Compliance with LoRaWAN

1.0.2 Class A

Frequency plan of LoRaWAN

EU868 / US915

Power of transmitter, dBm

14 / 20

Network Registration Method

ABP/OTAA

Real time clock

built-in

Magnetic sensor

built-in

Motion detector

built-in

Data archive

daily, events

Built-in battery

3.6V Li-SOCl2 D

Capacity, mAh

18000

The number of "open-closed" cycles, times / month

> 10

Maximum flow rate Qmax, m³/h

25

Overpressure of the ambient, kPa

< 50

Ambient temperature, ° С

-25…+75

Gas temperature, ° С

-25…+55

Service life, years

> 8

Specifications :
Seller Smartico, LLC
Manufacturer name Smartico
SKU 1689-11253
Manufacturer Part number V-LR
Product Attributes Metering
RF Region EU868 - Europe 863-870MHz
LoRa Class Class A
Solution Represented Smart Cities, Energy and Utilities, Smart Industries, Smart Building, Smart Metering
Power supply Non rechargeable battery
Battery specification (Wh) 18000
Battery type Other
Output throughput (mW) 25/100
RF transceiver SX1276
Operating Temperature (min to max) -25 …+75°C
Technical datasheet

Smartico Gas Shutoff Valve LoRaWAN

Lead-time if backordered (in working days) 45-60
Lead-time if in Stock (in working days) 3
