StormSens Lightning Storm Detector US915

$374.31
(VAT excluded)
In stock
Usually delivered in 5 working days
Commercially available
This product is already in mass production. Production batches are in route or stock is available. All certifications for the regional areas where the products are sold are obtained from competent institutions.

Key features highlights :

  • Dimensions: 122mm x 82mm x 55mm
  • Lightning Activity detection radius of approximately 40km.
  • Network Interface: LoRaWAN Class A, OTAA or ABP
  • US915 MHz
  • Power: Solar-cell and battery powered for easy installation and maintenance.
  • Fastening Cable Ties and Wall Mounts
  • 1 On-Off Power Button
  • 1 LED for Configuration and Authentication
  • RoHS certified
  • Intra and inter-cloud lightning detection.
  • Distance estimation.
  • Interference and false detection rejection.
  • Single Lightning Energy Estimation.
  • Waterproof Enclosure (IP67)
  • OTAA or ABP

Description :

The StormSens LoRaWAN-compliant wireless lightning detector. It can detect approaching thunderstorm activity within a radius of 40km. It can determine its approximate distance, the energy level of individual lightning strikes and uses fine-tuned algorithms to reject man-made interference to prevent false positives. It is enclosed in an IP67-rated waterproof enclosure so that it can resist all outdoor weather conditions.

Installing lightning storm early warning systems that help companies and government warn their staff about approaching thunderstorms and save tens of thousands of dollars in asset and liability damage. By immediately knowing when a storm becomes dangerous, companies are able to move people and assets to safety. This product is ideal for outdoor activity centres such as golf courses, marinas and outdoor parks where lightning events can be deadly. It can also act as an early warning system to protect infrastructure assets (such as those found in airports or power distribution systems) sensitive to lightning events.

It operates entirely on a solar panel and battery so there is never a need to charge the device or replace the battery. Once it is installed, it can be left alone indefinitely while it sends battery levels and status reports every 10 minutes. It ships with a set of wall-mounting brackets so that it can be screwed to a wall or tied to a pole through cable ties.

It is compatible with any standard LoRaWAN network as a Class A device. By default, it connects to the network through OTAA but it is also configurable through ABP. Key system parameters can be changed dynamically through downlink messages to the device.

https://www.villotec.com/lorawan-lightning-detector

Specifications :
Seller Villotec
SKU 340-1628
Manufacturer Part Number VL-100-LRW
Seller SKU VL-100-LRW
Product Attributes Temperature
RF Region US915 - US 902-928MHz
Solution Represented Smart Cities, Other, Smart Operations, Daily Life
Battery specification (Wh) 1200
RF Power (dBm) 14
Antenna External on connector
RF transceiver SX1276
Interfaces Other
Other interfaces BLE
Depth (cm) 82
Width (cm) 55
Height (cm) 12.2
Lead-time if backordered (in working days) 15
Lead-time if in stock (in working days) 5
