ThingPark Enterprise all-in-one with Browan Outdoor Gateway

Build your own entry-level, single gateway, LoRaWAN private network in no time with ThingPark Enterprise All-in-One. This kit includes a preconfigured gateway with an embedded LoRaWAN Network Server + Join Server. It is suitable for mono-gateway small-scale deployments in outdoor environments such as industrial IoT applications.


For detailed documentation and step-by-step setup instructions for this kit, refer to the Product information/Technical documents section below and to our online documentation portal.

$949.80
(VAT excluded)
In stock
Commercially available
This product is already in mass production. Production batches are in route or stock is available. All certifications for the regional areas where the products are sold are obtained from competent institutions.

Key features highlights :

This entry kit with a single gateway license seamlessly upgrades to multiple gateways with ThingPark Enterprise SaaS platforms (Europe, USA, APAC/Australia, Russia...), to increase the quality of service via RF macro-diversity or to scale up the coverage/capacity of your IoT deployment. Device configuration and state are preserved through the upgrade.

ThingPark Enterprise is the leading industrial LoRaWAN private networking solution, already managing over 35,000 commercial gateways worldwide:

  • Streamline IoT network operations. The UI provides wizards to easily manage the LoRaWAN network and feed data to IoT applications. Dashboards provide key operational insights & alarm management.
  • Dependable industrial infrastructure leveraging the same technology trusted by leading service providers to deliver a secure and field-proven solution. Our ISO 9001 QA process (1,000+ tests and 4 weeks of field testing), ensures that you will never have to serve thousands of orphaned devices.
  • Any use case, anywhere. With 7+ years of field experience worldwide, we support the integration of remote sites for all regional radio regulations and offer the widest device interoperability, including a large driver library and the ability to add custom drivers. ThingPark offers hardware-independent gateway management tools, and ready-to-use Connectors to AWS IoT Core, Azure IoT & IoT Central and other leading IoT back-end platforms.

Dedicated to enterprise networks, ThingPark Enterprise streamlines your digital transformation, eliminating wiring of sensors, enabling indoor/outdoor tracking and many other use cases to optimize your activities.

Browan Outdoor Micro Gateway Specifications


  • Compliance with LoRaWAN 1.0.3
  • Up to 8 concurrent channels
  • 3G/4G backhaul supported
  • Long-range over 15 kilometres radius
  • 1 LAN port (10/100Mbps) with PoE
  • Support LoRa Basic Station & AWS IoT Core
  • Downlink LBT
  • Support background scan
  • Cloud service to support easy deployment
  • Provides full redundancy coverage
  • IP67 waterproof
  • Support Ubuntu OS

Kit Content


1 x Browan Outdoor Micro Gateway

1-year access to ThingPark Enterprise all-in-one

1-year support and maintenance

NoteGateway accessories are not included in the pricing. A separate antenna needs to be purchased.

Description :

A ThingPark Enterprise-Ready Outdoor Gateway to create your LoRaWAN network in no time...


Browan proposes in this Outdoor Micro Gateway the LoRaWAN technology designed to connect low-cost, battery-operated sensors over long distances in though environments that were previously too challenging or expensive to connect. Because of its long-range, high penetration, and high sensitivity capabilities, it is a much more cost-effective way for service providers to deploy the LoRaWAN® network for tracking applications than to use the GPRS network.

The Outdoor Micro Gateway is specially designed for wide area smart city applications. The applications include, but are not limited to automatic meter reading, monitoring fault indicators, monitoring streetlights, etc. A typical deployment is using star network configuration as a mobile network base station. This product can be configured as a last-mile repeater to solve sensor connectivity issues when the sensor is located at the edge of the coverage or out of coverage. It is a cost-effective way to provide full redundancy coverage for the entire service area.

...Designed to make IoT projects secure, fast, simple, flexible and cost-effective

It is perfectly suitable for small deployment requiring a single gateway without RF redundancy.

Benefits

  • State-of-the-art NS and JS.
  • Device & Gateway management (e.g. bulk device import, device catalogues, etc).
  • Node-Red interface for easy integration to the application server.
  • Enhanced battery lifetime due to the Advanced ADR algorithms.

Integrating external Applications via Node-Red

  • Node-Red provides a browser-based editor that makes it easy to wire together flows using a wide range of nodes​.
  • TPE-All-in-One is fully integrated with Node-Red application, through Single Sign-On. The product is pre-configured with default MQTT flows for both uplink and downlink​.
  • Use Node-Red editor to define specific routing/parsing functions and configure other protocol types (e.g. HTTP…).
Specifications :
Seller Actility
Manufacturer name Browan
SKU GRP-TAO-GEM-OUT-1-25
Product Attributes Gateway
Solution Represented Smart Cities
Power supply Energy harvested
Power supply 55VDC/0.6A via PoE adapter (Microsemi PD-9001GR 802.3at)
Antenna External on connector
RF transceiver SX1301, Other
Other interfaces 1 WAN port, 2 LoRa antenna connectors, 1 GPS antenna connector, one 3G/4G antenna (optional), SIM card slot (optional)
Depth (cm) 66
Width (cm) 200
Height (cm) 230
Certification CE, FCC, NCC, Other
Technical documents
Seller conditions Seller commercial condition
Seller shipping condition
